MODEL:HS-50 Single Output Switching Power Supply

MODEL

HS-50-5

HS-50-12

HS-50-15

HS-50-24

HS-50-48

OUTPUT

DC Voltage

5V

12V

15V

24V

48V

Voltage Tolerance

±2%

±1%

±1%

±1%

±1%

Rated Current

10A

4.2A

3.4A

2.1A

1A

Current Range

0-10A

0-4.2A

0-3.4A

0-2.1A

0-1A

Rated Power

50W

50.4W

51W

50.4W

48W

Ripple & Noise

75mVp-p

100mVp-p

100mVp-p

100mVp-p

100mVp-p

DC Adjustment Range

+10,-5%

±10%

±10%

±10%

±10%

Setup, Rise, Hold Time

200ms,100ms,20ms at full load

INPUT

Voltage Range

85～132 VAC/170～264VAC 47～63 Hz； selected by switch 240～370VDC

AC Current

1.3A/115 V 0.65A/ 230 V

Efficiency

71%

78%

78%

82%

84%

Inrush Current

Cold start 18A/115V 36A/230V

Leakage Current

＜1 mA/240VAC

PROTECTION

Over Load

110%～160%

Protection: Shut down o/p voltage, re-power on to recover

ENVIRONMENT

Working Temp., Humidity

-10℃～+60℃；20%～90 %RH

Storage Temp., Humidity

-20℃～+85℃；10%～95 %RH

Vibration

10～500Hz，2G 10min./1cycle, period for 60min, each along X, Y, Z axes

SAFETY

Withstand Voltage

I/P-O/P:1.5KVAC I/P-O/P:1.5KVAC O/P-FG: 0.5KVAC

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC

STANDARD

Safety Standard

Design refer to UL1012

EMC Standard

Design refer to FCC Part15 J Conduction Class B

OTHERS

Weight

0.51Kg

Packing

30pcs/15.8Kg/0.99CUFT

NOTE

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12″twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor.
3. Tolerance: includes set up tolerance, line regulation and load regulation.
